Vieux Fort Water Supply Redevelopment Project
St. Lucia, W. I.
The Vieux Fort Water Supply Redevelopment Project is part of a list of several island wide water supply improvement projects with the specific objective of achieving a sustainable supply of potable water to all of the residents and businesses of Vieux Fort. Under the project contractors, Vinci Construction Grand Projects (S.A.S.), Amarna was sub-contracted to produce:
1.Civil engineering and structural design drawings and calculations for the building components of Grace and Beausejour Water Treatment Plants (WTP) sites
2.Civil engineering and structural design drawings and calculations for the intake components of the Grace and Beausejour Raw Water Intake (RWI) sites
Volet River Crossing
St. Lucia, W. I.
The Volet Culvert Crossing, located in Micoud, is one of the critical culvert crossings along the East Coast Highway which connects Castries to Vieux Fort. In December 2013 Saint Lucia experienced the Christmas Eve Trough, which resulted in the extensive damage to the Volet Culvert Crossing.
As the Design Consultants for this project ACL’s role is to prepare preliminary designs for the suggested reinforced concrete culvert but also to present alternative options while comparing the cost benefit analysis for each option. Through preparation and/or analysis of topographic surveys/mapping, hydrological/hydraulic conditions and geotechnical conditions, preliminary designs for the initial box culvert were prepared, as well as for the alternative options of a composite arch bridge and right portal bridge.
Rehabilitation of Primary and Secondary Roads,
St. Lucia, W. I.
In an effort to further improve Saint Lucia’s national road system The Ministry of Infrastructure, Ports Energy and Labour has initiated the largest single investment in roads being made by a government here in Saint Lucia. Valued at US$42 million, the Road Improvement and Maintenance Program (Phase IV) aims to deliver complete reconstruction of approximately 81km of roads in various communities for the benefit of citizens island-wide.
The government of Republic of China, Taiwan (ROCT) and government of Saint Lucia have engaged Overseas Engineering & Construction Cooperation (OECC) to undertake design and construction of the roads. They, in turn, have engaged Amarna as local sub-designers to provide complete detailed engineering designs for over 29m of road reconstruction located in Dennery, Micoud and Soufriere.
Reinstatement and Slope Stabilization Works for Guesneau Access Road
St. Lucia, W. I.
The objective of the project was to re-establish access between the Guesneau and Babonneau communities by reinstating the damaged road and the construction of slope stabilization measures to protect against any future occurrences. The damage extended to a 179m section of road which was completely destroyed thus requiring road rehabilitation works which included soil retention structures, culvert/drainage structures, road works, and measures to protect slopes and road infrastructure from damage during future precipitation events.
As Resident Engineers/Project Managers on this project, ACL role included: assisting the MIPST in negotiations of contracts for the construction works; reviewing and certificating design of a MSE Wall; supervising and inspecting the execution of all construction activities performed by the contractor.
Rehabilitation/Reconstruction and Slope Stabilization Works for Grenada Roads
Grenada, W. I.
The objective of this project was to construct slope stabilization and protection structures to replace and protect roads damaged during heavy precipitation events in 2011 in Grenada. Six critical locations were identified, in the parish of St. John, for road rehabilitation works including soil retention structures, drainage works, road works, and measures to protect slopes and road infrastructure from damage during future precipitation events.
As the Design Consultants for this project ACL’s role is to conduct a detailed engineering assessment of the proposed preliminary designs and advise on their feasibility; assess the hydraulic capacity for the existing culverts; propose alternative designs and conduct comparative analyses to select the most appropriate and least cost solution and ultimately produce detailed designs and cost estimates of the chosen option for each of the selected are. ACL was also responsible for identifying climate change vulnerabilities and resilience building options.
Rehabilitation/Construction and Slope Stabilization Works for Agricultural Feeder Roads in St. Vincent
St. Vincent & the Grenadines, W. I.
The objective of the project was the rehabilitation and/or construction of 10km of agricultural feeder roads around the island in order to increase access to agricultural markets and social services in St. Vincent. Eight (8) locations were identified for construction/rehabilitation and/or expansion infrastructure works including soil retaining structures, culvert bridge repair and extension, drainage works, and road works.
As the Consultants for this project ACL’s role was to undertake the verification of selected roads, review and approve the existing engineering design drawings and cost estimate; undertake any new engineering design and cost estimates as required; assessment and design for hydraulic capacity for culvert and roadside drainage; assist in tender document preparation and evaluation; and ultimately carry out the supervision of the rehabilitation of the selected feeder roads.
Rehabilitation/Construction and Slope Stabilization Works for Dominica Agricultural Feeder Roads
Commonwealth of Dominica, W. I.
The objective of the project was the rehabilitation and/or construction of 70km of agricultural feeder roads in order to allow for access from the agricultural belts of the island to the main ports. Four (4) Project Sites were identified around Dominica’s Agricultural Regions for construction/ rehabilitation infrastructure works.
As the Consultants for this project ACL’s role was to undertake the verification of selected roads, review and approve the existing engineering design drawings and cost estimate; undertake any new engineering design and cost estimates as required; assessment and design for hydraulic capacity for culvert and roadside drainage; assist in tender document preparation and evaluation; and ultimately carry out the supervision of the rehabilitation of the selected feeder roads.
Feaibilith Study for the Development of the Millet Intake within the John Compton Dam Raw Water Supply System
St. Lucia, W. I.
The Millet Intake is a diversion dam constructed on an elevated tributary of the Millet River. Damage to the intake caused by Hurricane Tomas and siltation have cause variation/shortfall in the level of water it diverts from the Millet River to the Northern section of the island. In a effort to re-establish the Millet Intake as a primary source of raw water for the north of the island, the Water and Sewage Company (WASCO) has undertaken a feasibility study for the re-construction of the Millet Intake and the associated raw water line.
As local sub-consultants under R.J. Burnside out of Cananda, ACL’s role on this project included the preparation of a detailed topographical survey of the selected site for the intake structure; geotechnical investigation including borehole drilling; onsite local expertise and support for the location and design of the intake structure; and local administrative support.
St. Vincent Port Modernization Project
St. Vincent & the Grenadines, W.I.
The Government of St. Vincent and the Grenadine, under the execution of their Port Authority are currently undertaking the modernisation of their port facilities through the construction of a new cargo port in Kingstown. The proposed site for the Kingstown Port Extension runs along 600m of undeveloped coastline North-West of the existing Port facility starting from the fisherman’s jetty to ‘Bottom Town Beach’. The port will extend approximately 100mm from the shoreline adjacent to the central business district in Kingstown.
Under the helm of Sellhorn Ingenieurgesellschaft mbH, ACL’s role on this project was to provide geotechnical investigation: topographic survey; bathymetric survey; and traffic study of the marine area chosen for the future location of the New Kingstown Port in St. Vincent.
Dominica West Coast Road Culvert Assessment
Commonwealth of Dominica, W. I.
The objective of this project was the assessment of over 200 culverts along the Edward Olivier Leblanc Highway on the island of Dominica. This came as a result of the Common Wealth of Dominica’s concerns over the low drainage capacity of the existing culverts given the recent adverse weather conditions in the region.
ACL’s role was to carried out site investigation of all culverts and propose upgrading or remedial measures to the existing culverts based on site investigations and hydraulic designs
Dominica Coconut Products (DCP) Rehabilitation Works
Commonwealth of Dominica, W. I.
DCP, closed down operations in November 2015 after it was severely affected by flooding as a result of heavy rainfall associated with the passage of Tropical Storm Erika in August 2015. The nearby river overflowed its banks and inundated the premises, causing major damage to the property and sweeping equipment and products into the sea.
As sub-consultants on the project, ACL was responsibility for the producing engineering design drawings for the rehabilitation works to the site which included retaining wall and protective berm details, bridge details, security wall and gate details and septic tank details.
Civil Infrastructure Design for Cinnamon Hill Development
St. Lucia, W. I.
Cinnamon Hill is a proposed 26.82 acres mixed-use residential and commercial development located in Des Rameaux, Gros Islet. The residential portion of the development comprises 122 middle income 2 and 3 bedroom single family houses, with an open concept kitchen/living /dining area floor plan. The commercial area of the development will comprise a start of the art shopping/business complex.
As consultants on this project, ACL’s services included the review/redesign of the proposed civil infrastructure for the road network, subdivision layout, water reticulation and sewer disposal for the entire 26 acre site.
Civil Infrastructure Design for Belair Estate Development
St. Lucia, W. I.
Belair Estate is a proposed mixed-use residential and commercial development that covers 52 acres of land in the Belair area of Roseau Valley. The proposed development boast 229 single family 2-bedroom/1-bath and 3-bedroom/2-bath units, each with a open concept kitchen/living/dinning area floor plan. To accommodate the development’s occupants, Belair Estate will also be homes to its own self-contained commercial centre. Seated on just over an acre of land, the commercial centre will include amenities such as a green grocer/minimart, bakery/coffee shop, ice-cream parlour, day-care centre, gym, doctor’s office and pharmacy among other facilities. A public recreational park .
As consultants on this project, ACL’s services included the production of the conceptual designs for the civil infrastructure and structural designs for the entire project. These included the road network, subdivision layout, water reticulation and sewer disposal for the civil infrastructure works.
Civil Infrastructure Design for Shangri La Estate Development
St. Lucia, W. I.
This 2 acre residential development consist of eight 2 and 3 bedroom single and multi storey detached units located in Balata, Castries.
Our contract on this project included the civil engineering design drawings for the master plan including the road network, infrastructure and subdivision layout; and structural engineering design drawings for the residential units and the project management and construction supervision.
Civil Infrastructure Design for Sea View Heights Development
St. Kitts & Nevis, W. I.
Sea View Heights is the first purpose built medical student housing in St. Kitts. the development seating on 6 acres of land and consist of various apartment and villa structures, club house, pool, shopping and multiple meeting and study facilities.
As consultants on this project our role included the engineering design for earthworks, pavements, drainage, waste water system review, specifications and detailing and all associated civil structures including but not limited to retaining structures and decorative walls, walkways, parking and footpaths.
Rehabilitation Works for the John Compton Dam Access Road
St. Lucia, W. I.
The objective of the project was the upgrade to secondary road access to John Compton Dam in order to further under the main project works of rehabilitation to the John Compton Dam. The site posed a challenge for accessibility of the heavy equipment required for this Project and thus required substantial upgrading of the existing access road to allow for access to the dam.
Rehabilitation/Reconstruction and Slope Stabilization Works for Ti Rocher Road
St. Lucia, W. I.
The objective of the project is to construct slope stabilization and road reinstatement structures to replace section of the Ti Rocher road damaged during recent heavy precipitation events. The road reinstatement and slope stabilization works including the design and reconstruction of a retaining wall of approximately 5 metres maximum height and road infrastructure.
